Declassified by MG Richard A. Harrison USCENTCOM Chief of Staff Bettm'l'if!fMM!f Declassified on: 8 October 2025 • Towed Decoy Software Load or Mission Data: MTP AA51 • Num Towed Decoys: 2 • Type of Radar-Guided AAM: AIM-120 • Num Radar-Guided AAM: 2 • Type of IR-Guided AAM: AIM-9X • Num IR-Guided AAM: 2 • Gun Name or Designator: M61Al • Num Gun Rounds: 510 • Air-to-Ground Wpn to Include Num of Each:l.___ _ _1_.4_a_ _ ___, • TGT Pod Name or Designator: SNIPER LDP • Additional Avionics: HTS-P R7.85 • Data Link: LINK 16 • Gentext: ACEQUIP • Aircraft Callsign: 1.4a L---,--......,....----,.....r---, • Radar Name or Destination 1.4a, 1.4g • Radar Software Load or Mission Data: 8070 / MMC 7.3 • Radar Warning Receiver (RWR) Name or Designator: ALR-56M • RWR Software Load or Mission Data: 102 / SY0730 • MWS Name or Designator: • MWS Software Load or Mission Data: • IRCM Name or Designator: • IRCM Software Load or Mission Data: • ECM Name or Designator: ALQ-184 • ECM Software Load or Mission Data: C01856 • CMD Name or Designator: ALQ-213 • Chaff Designator: RR-180 • Num Chaff or Cartridges: 60 • Flare Designator: MW-53, Mm-66 • Num Flares: 45 • Towed Decoy Name or Designator: ALE-50 • Towed Decoy Software Load or Mission Data: MTP AA51 • Num Towed Decoys: 2 • Type of Radar-Guided AAM: AIM-120 • Num Radar-Guided AAM: 2 • Type of IR-Guided AAM: AIM-9X • Num IR-Guided AAM: 2 • Gun Name or Designator: M61Al • Num Gun Rounds: 510 • Air-to-Ground Wpn to Include Num of Each:l.___ _ _1_.4_a_ _ _..... • TGT Pod Name or Designator: SNIPER LDP 3.5c, FOIA Exemption (b)(6) iECl&ll.il?JrQPQM MDR 25-0094 thru MDR 25-0099 / JS-250710-TM8S 10/17/25 004 Approved for Release to AARO
Vision Description (EN)
Page displays aircraft weapons and avionics loadout specifications in two repeated sections labeled with equipment categories (Towed Decoys, Radar-Guided AAM, IR-Guided AAM, Gun systems, etc.). The document lists specific system designators (AIM-120, AIM-9X, M61A1, SNIPER LDP, ALR-56M, ALQ-184, etc.) with corresponding quantities. Multiple fields contain redactions marked (b)(6) protecting sensitive operational callsign and radar destination information. A declassification banner appears in the header; a FOIA exemption (b)(6) note is visible in the footer with MDR reference numbers and AARO release approval dated 10/17/25.
Descrição Vision (PT-BR)
A página apresenta especificações de carga de armas e aviónica de aeronave em duas seções repetidas rotuladas com categorias de equipamento (Towed Decoys, Radar-Guided AAM, IR-Guided AAM, Gun systems, etc.). O documento lista designadores específicos de sistemas (AIM-120, AIM-9X, M61A1, SNIPER LDP, ALR-56M, ALQ-184, etc.) com quantidades correspondentes. Múltiplos campos contêm redações marcadas (b)(6) protegendo informações sensíveis de indicativo operacional e destino de radar. Um carimbo de desclassificação aparece no cabeçalho; uma nota de isenção FOIA (b)(6) é visível no rodapé com números de referência MDR e aprovação de lançamento da AARO datada de 10/17/25.
